Ecotec Single Nozzle Smart Fuel Dispenser for Petrol Station



Model Number
Fuel Dispenser
place of origin
Zhejiang, China
brand name
Ecotec
Product name
Fuel Dispenser
Flow rate
5-55L/MIN
Nozzle Number
1 Nozzle
Meter
1 x Tatsuno Meter
Pump
1 x Tatsuno Pump
Motor
220V 50hz
Hose
3/4 inch 4 meter long
Screen
Smart Touch Screen
Weight
240KG
Package
Wooden box or Carton

  • S112

  • ECOTEC

Availability:
Quantity:
Inquire Add to Basket

For 4 nozzle:

Fuel Dispenser S111

2 x Product (Submersible type)
2 x Tatsuno pump
4 x Tatsuno meter
4 x nozzle 11A, 3/4" NPT, outlet: 13/16"
4 x Black, length:4 M with coupling
4 x Solenoid valve MSF-20BA
4 x Breakaway valve, 3/4 inch
2 x Electronic controller WA122,with RS485
2 x Preset keyboard Z26, white color
4 x Display board X110,886, white
All Painting Body
Power supply: 220V, 50hz
Package: Standare Export caton
With one printer, NO LIGHT



Specification


Pump
Type
Optional(Tatsuno/Bennet/Tokheim)
Inlet pressure
≥54kPa.
Flow Rate(L/MIN)
55±5
Suction Distance(m)
6(vertical meter) / 50(horizontal meter)

Flow Meter
Type
Optional
Accuracy
±0.2%

Motor
Voltage(V)
110V/220V/380V, 50Hz/60Hz
Capacity(hp)
1.5HP(0.75kw),2HP(1.1KW)
1HP
(0.75kw)

Input Voltage
12V/24V/110V/220V/380V,50HZ/60HZ


Nozzle
Auto Shut-off Nozzle


Environmental Condition
-40ºC~~+55ºC
-40ºC~~
+55ºC

Control Type
Solenoid Vale Control Type


Preset
Function Provided(Small LCD Indicator)




Display
(Counter)
Type
LCD and Bright Backlight


Digit of Volume
0~~999(6 Digits), Decimal point can be changed


Digit of Amount
0~~999(6 Digits), Decimal point can be changed


Digit of Unit Price
0~~999(6 Digits), Decimal point can be changed


Digit of Total Range
0~~99, 999, 999, 99


Totalizer

Totalizer
1~~9, 999, 999
Hose

4 M


Weight

250KG


Dimension(L*W*H)

1060*600*2200(mm)


Qty of Container

40FT: 66pcs 20FT: 22pcs
