RTC
Ecotec
8537101190
| Quantity: | |
|---|---|
Functions and Features
Supports control of multiple fuel dispensers, simultaneously controlling multiple fuel dispenser nozzles for fueling and printing fueling data. Maximum of 12 fuel dispensers and 20 nozzles.
Supports remote control of multiple fuel dispensers. Wired control distance is close to 200 meters.
During fueling, real-time display of fuel volume and unit price. Fueling can be stopped at any time or switched to another fuel dispenser.
Supports multiple protocols and can control fuel dispensers with different protocols simultaneously.
Fueling records can be stored locally. Each nozzle can store more than 4000 records. Supports search by serial number and time.
Operation records (parameter and setting changes) can be stored locally. Supports time-based search.
Built-in automatic fault detection function with error code display.
Keyboard operation with fast response and rich functionality.
Dual menu design (read-only menu and full menu) with different levels of passwords used to unlock the menus, making it easy to locate and select function options.
Supports cloud control. The cloud can control and query fuel dispensers via RTC.
Supports multiple network communication modules.
Supports cloud online upgrade and program download for fuel dispenser upgrade.
Reserved TTL interface for future expansion
Main Parameters
| Power Supply | DC 5V/2A |
| Operating Temperature | -10ºC~+70ºC |
| Storage Temperature | -10ºC~+70ºC |
| Display | 3.5-inch LCD, resolution 320×480 |
| RS485 Communication Distance | within 199 meters |
| Keyboard Life | ≥ 50 million presses |
| Cloud Communication | WIFI / 4G / RJ45 |
| Weight | approx. 1800g |
| RTC Battery | CR2032 3V |
WENZHOU ECOTEC ENERGY EQUIPEMNT Co., Ltd as a professional supplier of Petroleum equipment, Energy device, can offer customer the better products with better price.
Ecotec Energy is founded in 2019, but the Ecotec team are all with experience for over 10 years. We can provide complete package service from Design, Manufacturing, Delivery and after-sale service, we have exported to over 60 countries now, and have agent in Africa, Middle East, Asia and South American countries.
Here Eectec Energy are on the position to offer the below products:
1. Fuel station: Fuel dispenser, Pump, Meter, fuel accessories, Adblue and container stations
2. LPG station: LPG dispenser, LPG pump, LPG meter, LPG Tank, LPG skid and other LPG station equipment
3. CNG station: CNG dispenser, CNG compressor, CNG cylinder and skid type CNG station
4. LNG Station: LNG dispenser, LNG pump, LNG pumping skid, LNG vaporizer etc
5. Valves for petroleum industrial: Ball valve, Gate Valve, Global valve, Check valve with different standard
6. Station Automation system: Station Retail system, Cell phone APP system, Tank Gauging system
7. Auto Parts: Tyre inflator, Wheel Balancer, Car Washing Machine etc
Customer and Dedication is what we standing for, we will always focus customer′s need, and struggle for it, Looking forward to cooperate with you.
