Model LPG-Z-SY-a
ECOTEC
| Quantity: | |
|---|---|
Ecotec design and manufacturing
Precise, convenient and safe, Customer and user first is the top priority in Ecotec design and manufacturing, J series is the dispenser with highest accuracy, quality, durability and reliability that always provides utmost satisfaction for all
Owner and User
Fuel dispenser J series is the essential dispenser for service stations, benefits to both service station owners and drivers, user-friendly and safe best partner that provide greatest fulfillment for all
Wide Range of product lineup
Product lineup meets various requirement of sites and customers, the best model with the best function,
suitable for single nozzle to 8 nozzle
suitable for both suction and submersible
suitable for Gilbarco, Tatsuno, Tokhem Bennett, LPG and CNG dispenser
suitable for regular flow rate and high flow rate
Option with TV, LED, Printer, Bank Card reader etc
| Pump | Type | Optional |
| Inlet Pressure | ≥54kPa. | |
| Flow rate (L/min.) | 55±5 | |
| Suction Distance (m) | 6(vertical meter) / 50(horizontal meter) | |
| Flow Meter | Type | Optional |
| Accuracy | ±0.2% | |
| Motor | Voltage(V) | 110V/220V/380V,50Hz/60Hz |
| Capacity(hp) | 1HP(0.75kw) | |
| Input Voltage | 110V/220V/380V,50Hz/60Hz | |
| Nozzle | Auto Shut-off Nozzle | |
| Environmental Condition | -40ºC~~+55ºC | |
| Control Type | Solenoid Vale Control Type | |
| Preset | Function Provided(Small LCD Indicator) | |
| Display(Counter) | Type | LCD and Bright Backlight |
| Display(Counter) | Digit of Volume | 0~~999,999(6 Digits),Decimal point can be changed |
| Digit of Amount | 0~~999,999(6 Digits),Decimal point can be changed | |
| Digit of Unit price | 0~~9999(4 Digits),Decimal point can be changed | |
| Digit of Total Range | 0~~99,999,999,99 | |
| Optional Display | Type | LCD and Bright Backlight |
| Digit of Volume | 0~~99,999,999(8 Digits),Decimal point can be changed | |
| Digit of Amount | 0~~99,999,999(8 Digits),Decimal point can be changed | |
| Digit of Unit price | 0~~999999(6 Digits),Decimal point can be changed | |
| Digit of Total Range | 0~~99,999,999,99 | |
| Totalizer | 1~~9,999,999 | |
| Hose | 4.5m | |
| Weight | 205kg | |
| Dimension(L×W×H) | 1060*600*2200(mm) | |
| Dimension(L×W×H)Of Qty of Container | 40ft: 44 20ft: 22 | |
