Ecotec Technotrade Atg Pts Controller for Station Management System Gilbarco Tatsuno Tokheim

Home » Products » LPG Station » LPG Dispenser » LPG Gas Dispenser » Ecotec Technotrade Atg Pts Controller for Station Management System Gilbarco Tatsuno Tokheim

This product is no longer available

Ecotec Technotrade Atg Pts Controller for Station Management System Gilbarco Tatsuno Tokheim

Share to:

Ecotec Technotrade Atg Pts Controller for Station Management System Gilbarco Tatsuno Tokheim

Model:
ET-lpg
Brand:
ECOTEC
Code:
FDET-BC112

Availability:

Product Description

Products Description

Product Description

APPOINTMENT

PTS-2 forecourt controller for petrol stations is a powerful modern forecourt controller for provision of control over:

−	petroleum, LPG and CNG dispensers
−	automatic tank gauge systems and probes
−	price boards
−	RFID readers

Its dimensions are extremely small with a size of a credit card, which makes its suitable for installation inside any third-party hardware.

PTS-2 controller knows communication protocols of a great variety of dispensers, ATG systems and probes, price boards and readers allowing to control over any of them in a common way regardless of the brand or communication protocol used, so using the PTS-2 controller any management system (POS system, OPT, mobile application) can use a common way for provision of control over any supported brands in the same
way.

COMPLETE SET

Depending on the order code (see section "Order information") PTS-2 controller can be supplied either in a view of electrical board (variant of controller supply PTS2-PCB-z), or installed in a mounting box with cables inputs and a power switching button (variant of controller supply PTS2-BOX-z).

Variant of controller supply in a view of electrical board (PTS2-PCB-z)

FuelPlus+ Station Management System

- Oil depot, oil tanker trailer, Fuelplus can manage the fuel dispenser, ATG, LED price boardand other device by means of Rs485, Rj45, Lora,wifi,4G/3G and GRPS with database on doudorlocal basis

- Available on PC, Laptop, Cell phone both i0S and android, as well as other paymentterminal(POS)

- Fuelplus can set upcenter database to control and monitor all fleet stations, every stationcan have local management system to control the fuel dispenser, ATG,LED price, every fueldispenser can install POS terminal, IC card reader, lD card reader to achieve self-service,every ATG can linked to fuelplus timely - Fuelplus also can work as single station or single dispenser, also container station solution,you can install the application on can smart control screen or POS to achieve the control.itcan working without any PC

Products Specifications

Model List
Model	Separator	Flow Meter	Nozzle	Display	Flow rate LPM
LPG112	1	1	1	2	40 LPM
LPG122	1	2	2	2	40 LPM
LPG124	1	2	2	4	40 LPM
Nozzle number, product number ,flow rate all can be customized, contact for more details

Specification
Frame Options	Painted Galvanized Iron
Frame Options	Stainless Steel
Nozzle Options	1 – 2 – 4
Simultaneous Filing	1 – 2 – 4
Electronic Features	User friendly interface.
	Preset filings as money or volume/mass
	8x6x6 Digit classic or 6x6x5 Module LCD Screen options.
	2×16 Dot Matrix Information Screen
	Electromechanical and Electronic Counters
	Automatic temperature compensation based on ASTM Tables
	Alphanumeric Keyboard
Communication Protocol	Compatible with common protocols
Optional Electronic Peripherals	Printer
	SDCard Logger
	GPRS Modem
Flow Meter Options	Four Piston, Positive Displacement Meter
Flow Meter Options	Coriolis Mass Flow Meter
Flow Rate	5- 50 Liter/min.
Accuracy	± %0.2 ~ %0.5
Measurement Unit Options	Liter or Gallon for Volume
Measurement Unit Options	Kilogram or Pound for Mass
Temperature Range	-40 ºC /+55 ºC
Calibration Options	Electronic or Mechanic Calibration Options
Design Norms	ATEX, OIML and MID

Company Profile

WENZHOU ECOTEC ENERGY EQUIPEMNT CO., Ltd as a professional supplier of Petroleum equipment, Energy device, can offer customer the better products with better price. Ecotec Energy is founded in 2019, but the Ecotec team are all with experience for over 10 years. We can offer package service from Design, Manufacturing, Delivery to after-sale service, and we have exported to over 60 countries now, also have agent in Africa, Middle East, Asia and South American countries. Customer and Dedication is what we standarding for, we will alwasy focus customers need, and struggle for it, Looking forward to cooperate with you!

Exhibition

Ecotec frequently participate in exhibitions around the world to strengthen contact with customers and provide better services

Certifications

Ecotec produce products with higher standards than the industry, and have been certified by relevant institutions and have a variety of certificates.

Packaging & Shipping

Ecotec accept air, ocean, and land shipping, and will choose the most suitable packaging for you according to the shipping
transportation.

FAQ

1. Who are we?
We are based in Zhejiang, China, start from 2019,sell to Africa(30.00%),Eastern Asia(25.00%),Mid East(20.00%),South
America(5.00%),Southeast Asia(5.00%),South Asia(5.00%),North America(5.00%),Oceania(3.00%),Central America(2.00%). There are total about 100 stuff in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production; always final Inspection before shipment; quick respond after sale and full life tech support.

3.What can you buy from us?
FUEL DISPENSER,LPG TANK,LPG SKID,SUBMERSIBLE PUMP,Container Station

4. Why should you buy from us not from other suppliers?
WENZHOU ECOTEC ENERGY EQUIPEMNT Co., Ltd as a professional supplier of Petroleum equipment, Energy device, can offer customer the better products with better price. Ecotec Energy is founded in 2019, but the Ecotec team are all with experience for over

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Arabic
